Water Heater Pilot Assembly includes pilot thermocouple & tubing natural gas NG

Water Heater Pilot Assembly includes pilot thermocouple & tubing natural gas NG

This water heater pilot assembly is designed for use with natural gas water heaters. It includes a pilot thermocouple and tubing, ensuring a reliable ignition and safe operation for your heating needs.

Compatible Models

This pilot assembly fits many water heaters on the market.

• Various models

Specifications

Part Number	Water Heater Pilot Assembly
Replaces	Standard Pilot Assemblies
Length	24 inches
Fuel Type	Natural Gas (NG)
Includes	Pilot Thermocouple & Tubing

Signs You Need This Part

• Pilot light won't stay lit
• Abnormal clicking sounds during ignition
• Inconsistent water heating
• Gas leaks or smell near the water heater

Installation

1. Shut off the gas supply to the water heater.
2. Unplug the appliance or turn off power at the breaker.
3. Remove the old pilot assembly.
4. Install the new pilot assembly, ensuring proper placement of the thermocouple and tubing.
5. Reconnect the gas supply and check for leaks.

Frequently Asked Questions

Does the Water Heater Pilot Assembly fit all water heater models?

It fits many water heaters on the market, but compatibility should be confirmed with existing equipment.

Is this pilot assembly suitable for liquid propane (LP) water heaters?

This assembly is designed specifically for natural gas (NG) appliances only.

Does it come with installation instructions?

Installation instructions are not included; consult a technician for guidance if needed.

Can the pilot thermocouple be replaced separately?

This assembly includes the thermocouple and is sold as a complete unit.
