Packard PRMJ64 Motor Start Capacitor. 64-77 MFD UF / 330 VAC

Packard PRMJ64 Motor Start Capacitor

The Packard PRMJ64 Motor Start Capacitor is designed for use in air conditioning and motor starting applications. It operates with a capacitance range of 64-77 MFD at 330 VAC, providing reliable performance for HVAC systems.

Compatible Models

This part is compatible with various models that require a capacitor rated for motor start applications.

• 64-77 MFD UF
• 330 VAC

Specifications

Signs You Need This Part

• Motor fails to start or runs inconsistently.
• Capacitor is visibly damaged or leaking.
• Unusual humming noise from the motor.
• Loss of power or efficiency in the appliance.

Installation

1. Unplug the appliance from the power source.
2. Remove any covers or access panels to reach the capacitor.
3. Disconnect the old capacitor, noting the wiring configuration.
4. Install the new Packard PRMJ64 Motor Start Capacitor and connect the wiring as noted.
5. Replace covers and plug the appliance back into the power source.

Frequently Asked Questions

Does the PRMJ64 fit my AC model?

The PRMJ64 is compatible with most models that require a motor start capacitor rated between 64-77 MFD and 330 VAC.

Is the capacitor polarized?

This capacitor is non-polarized, making installation straightforward regardless of terminal connections.

What is the temperature range for the PRMJ64?

The operating temperature range is -40C to 65C (-40F to 149F).

Does it include terminals?

Yes, the PRMJ64 features standard 1/4" male terminals for easy installation.
